Name: RoadCenterlines

Display Field: NAME

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN STYLE="font-weight:bold;">Purpose: </SPAN><SPAN>Roads Authority may be used in applications requiring to display streets by ownership within the City of West Palm Beach. The attribute information describes ownership, maintenance responsibility and address ranges to support geocoding.</SPAN></P><P><SPAN /></P><P><SPAN STYLE="font-weight:bold;">Intended Use: </SPAN><SPAN>Geographic area used for display and analysis overlay in web applications</SPAN></P><P><SPAN /></P><P><SPAN STYLE="font-weight:bold;">Department: </SPAN><SPAN>All City Departments</SPAN></P><P><SPAN /></P><P><SPAN STYLE="font-weight:bold;">Data Source: </SPAN><SPAN>Layer in Transportation dataset</SPAN></P><P><SPAN /></P><P><SPAN STYLE="font-weight:bold;">How was the Data Manipulated</SPAN><SPAN>: GIS layer was created by Palm Beach County. The data changes frequently so City GIS should update the file quarterly from the County database. Last download was on March, 13th, 2023. </SPAN></P><P><SPAN /></P><P><SPAN STYLE="font-weight:bold;">How the Data is Modified: </SPAN><SPAN>Although not currently in a data maintenance workflow, The information is used by several departments (Planning, Engineering and Public Works) and a data maintenance governance needs to be established. Last download was on March, 13th, 2023. </SPAN></P><P><SPAN /></P><P><SPAN STYLE="font-weight:bold;">Update Frequency: </SPAN><SPAN>TBD - once a data maintenance governance needs to be established.</SPAN></P><P><SPAN /></P><P><SPAN /></P><P><SPAN /></P><P><SPAN /></P></DIV></DIV></DIV>

Service Item Id: fbb61c2a17784f3fa7c0ff59fcfe0bee

Copyright Text: City of West Palm Beach IT - GIS

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 909480.9999379963
YMin: 816839.9998908266
XMax: 971800.2499711625
YMax: 912178.9381495714
Spatial Reference: 2881  (2881)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: RESP_AUTH
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSLSSolid
Color: [130, 130, 130, 255]
Width: 3
Default Label:
UniqueValueInfos:
• Value: FDOT
  Label: FDOT
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [230, 152, 0, 255]
  Width: 3
• Value: MUN
  Label: MUN
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [0, 112, 255, 255]
  Width: 3
• Value: COUNTY
  Label: COUNTY
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [56, 168, 0, 255]
  Width: 3
• Value: PRI
  Label: PRI
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [132, 0, 168, 255]
  Width: 3
• Value: COURTESY
  Label: COURTESY
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [223, 115, 255, 255]
  Width: 3
• Value: ITID
  Label: ITID
  Description: N/A
  Symbol:
  Style: esriSLSSolid
  Color: [230, 230, 0, 255]
  Width: 3
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• SEGMENTID ( type: esriFieldTypeInteger, alias: SEGMENTID )
• STREET ( type: esriFieldTypeString, alias: STREET, length: 80 )
• PREFIX ( type: esriFieldTypeString, alias: PREFIX, length: 2 )
• NAME ( type: esriFieldTypeString, alias: NAME, length: 80 )
• TYPE ( type: esriFieldTypeString, alias: TYPE, length: 4 )
• SUFFIX ( type: esriFieldTypeString, alias: SUFFIX, length: 2 )
• FROMLEFT ( type: esriFieldTypeDouble, alias: FROMLEFT )
• TOLEFT ( type: esriFieldTypeDouble, alias: TOLEFT )
• FROMRIGHT ( type: esriFieldTypeDouble, alias: FROMRIGHT )
• TORIGHT ( type: esriFieldTypeDouble, alias: TORIGHT )
• L_ZIPCODE ( type: esriFieldTypeInteger, alias: L_ZIPCODE )
• R_ZIPCODE ( type: esriFieldTypeInteger, alias: R_ZIPCODE )
• L_MUNI ( type: esriFieldTypeString, alias: L_MUNI, length: 25 )
• R_MUNI ( type: esriFieldTypeString, alias: R_MUNI, length: 25 )
• RESP_AUTH ( type: esriFieldTypeString, alias: RESP_AUTH, length: 10 )
• TFARE_ROW ( type: esriFieldTypeString, alias: TFARE_ROW, length: 12 )
• FUNC_CLASS ( type: esriFieldTypeString, alias: FUNC_CLASS, length: 50 )
• SPEED_LIM ( type: esriFieldTypeDouble, alias: SPEED_LIM )
• LANES ( type: esriFieldTypeDouble, alias: LANES )
• CFCC ( type: esriFieldTypeString, alias: CFCC, length: 5 )
• SE_ANNO_CAD_DATA ( type: esriFieldTypeBlob, alias: SE_ANNO_CAD_DATA )
• DT_CHG ( type: esriFieldTypeDate, alias: DT_CHG, length: 8 )
• LN2020 ( type: esriFieldTypeInteger, alias: LN2020 )
• COUNTY_RD_ID ( type: esriFieldTypeInteger, alias: COUNTY_RD_ID )
• ONEWAY ( type: esriFieldTypeString, alias: ONEWAY, length: 100 )
• FNUM ( type: esriFieldTypeInteger, alias: FNUM )
• STREET_NAME_SEQ ( type: esriFieldTypeInteger, alias: STREET_NAME_SEQ )
• ZIPCITY ( type: esriFieldTypeString, alias: ZIPCITY, length: 50 )
• SHAPE ( type: esriFieldTypeGeometry, alias: SHAPE )
• SHAPE.STLength() ( type: esriFieldTypeDouble, alias: SHAPE.STLength() )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates
