Name: Water System Valve Inspection

Display Field: FACILITYID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>Purpose: The purpose of this feature service is to be used for water system valve inspections. The layers has fields to be completed from the valve inspection results. The layer will also be used in the Water Distribution and All Utilities Application. </SPAN></P><P><SPAN>Intended Use: Currently used for location and analysis purpose in the Water Distribution Viewer, mobile apps, Modeling, Dashboards and other Public Utility applications.</SPAN></P><P><SPAN>Department: Public Utilities Department - Water Distribution Division</SPAN></P><P><SPAN>Data Source: Referenced feature service on Enterprise portal - Water Utility Network dataset</SPAN></P><P><SPAN>How was the Data Manipulated: The feature layer was created by combining schema from the water system valves and inspection fields from an ESRI inspection solution. The service was published with all fields but when used in application not relevant to inspections, those fields will not be visible in the pop-ups. The feature layer's inspection fields will be updated by Water Distribution field crews once a valve inspection has been completed. </SPAN></P><P><SPAN>Update Frequency: As-Needed by Engineering, Public Utilities or Water Distribution supervisors. As inspection are performed by Water Distribution field crews updates will be made to the feature layer's attributes. </SPAN></P></DIV></DIV></DIV>

Service Item Id: 44d56d7152904065bc463d1ad1e1ee41

Copyright Text: West Palm Beach - GIS Use limitations This data is provided for reference purposes only. Any reliance on the information contained herein is at the user’s own risk. NO WARRANTY EXPRESSED OR IMPLIED IS MADE REGARDING THE ACCURACY, ADEQUACY, COMPLETENESS, LEGALITY, RELIABILITY, TIMELINESS OR USEFULNESS OF THE DATA. ALL WARRANTIES OF ANY KIND, EXPRESS OR IMPLIED INCLUDED BUT NOT LIMITED TO THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE DISCLAIMED.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 895955.5292855799
YMin: 819962.7278973237
XMax: 971780.7142490782
YMax: 903451.7092129886
Spatial Reference: 2881  (2881)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: true

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: SHAPE )
• FACILITYID ( type: esriFieldTypeString, alias: Asset-ID, length: 20 )
• INSTALLDATE ( type: esriFieldTypeDate, alias: Install Date, length: 8 )
• LOCDESC ( type: esriFieldTypeString, alias: Address, length: 200 )
• ROTATION ( type: esriFieldTypeDouble, alias: Rotation )
• DIAMETER ( type: esriFieldTypeDouble, alias: Diameter , Coded Values: [-1: Other] , [0: Unknown] , [0.75: 3/4"] , ...33 more... )
• VALVETYPE ( type: esriFieldTypeString, alias: Valve Type, length: 30 , Coded Values: [Ball: Ball] , [Butterfly: Butterfly] , [Cone: Cone] , ...6 more... )
• BYPASSVALVE ( type: esriFieldTypeSmallInteger, alias: Bypass Valve , Coded Values: [0: False] , [1: True] )
• CLOCKTOCLOSE ( type: esriFieldTypeSmallInteger, alias: Clockwise To Close , Coded Values: [0: False] , [1: True] )
• NORMALLYOPEN ( type: esriFieldTypeSmallInteger, alias: Normally Open , Coded Values: [0: False] , [1: True] )
• TURNSTOCLOSE ( type: esriFieldTypeInteger, alias: Turns To Close )
• OPERABLE ( type: esriFieldTypeSmallInteger, alias: Operable , Coded Values: [0: False] , [1: True] )
• HYDRFLAG ( type: esriFieldTypeSmallInteger, alias: Hydrant Valve , Coded Values: [0: False] , [1: True] )
• CURROPEN ( type: esriFieldTypeSmallInteger, alias: Currently Open , Coded Values: [0: False] , [1: True] )
• ENABLED ( type: esriFieldTypeSmallInteger, alias: Enabled , Coded Values: [0: False] , [1: True] )
• ACTIVEFLAG ( type: esriFieldTypeSmallInteger, alias: Active Flag , Coded Values: [0: False] , [1: True] )
• OWNEDBY ( type: esriFieldTypeSmallInteger, alias: Owned By , Coded Values: [1: Our Agency] , [-1: Private] , [-2: Other] , ...1 more... )
• MAINTBY ( type: esriFieldTypeSmallInteger, alias: Managed By , Coded Values: [1: Our Agency] , [-1: Private] , [-2: Other] , ...1 more... )
• FIELDVERIFY ( type: esriFieldTypeString, alias: Field Verified, length: 5 , Coded Values: [Yes: Yes] , [No: No] )
• NOTES ( type: esriFieldTypeString, alias: Notes, length: 200 )
• LASTUPDATE ( type: esriFieldTypeDate, alias: Last Update Date, length: 8 )
• LASTEDITOR ( type: esriFieldTypeString, alias: Last Editor, length: 50 )
• HYPERLINK ( type: esriFieldTypeString, alias: Hyperlink, length: 255 )
• InspectedBy ( type: esriFieldTypeString, alias: InspectedBy, length: 255 )
• InspectionDate ( type: esriFieldTypeDate, alias: InspectionDate, length: 8 )
• IsValveAccessible ( type: esriFieldTypeString, alias: IsValveAccessible, length: 255 , Coded Values: [Yes: Yes] , [No: No] )
• IsValveShownonMap ( type: esriFieldTypeString, alias: IsValveShownonMap, length: 255 , Coded Values: [Yes: Yes] , [No: No] )
• ValveNumberDifferent ( type: esriFieldTypeString, alias: ValveNumberDifferent, length: 255 , Coded Values: [Yes: Yes] , [No: No] )
• IsThereaTieCard ( type: esriFieldTypeString, alias: IsThereaTieCard, length: 255 )
• DirectiontoOpen ( type: esriFieldTypeString, alias: DirectiontoOpen, length: 255 )
• FoundIn ( type: esriFieldTypeString, alias: FoundIn, length: 255 )
• DirectionLeft ( type: esriFieldTypeString, alias: DirectionLeft, length: 255 )
• UsedWhileFlushing ( type: esriFieldTypeString, alias: UsedWhileFlushing, length: 255 , Coded Values: [Yes: Yes] , [No: No] )
• NumberofTurns ( type: esriFieldTypeString, alias: NumberofTurns, length: 255 )
• InspectionCompleted ( type: esriFieldTypeString, alias: InspectionCompleted, length: 255 , Coded Values: [Yes: Yes] , [No: No] )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• CONDITION ( type: esriFieldTypeString, alias: Condition, length: 30 , Coded Values: [Passed: Complete] , [Failed: Needs Repair] , [Inaccessable: Not Found] , ...1 more... )
